| Place of Origin: | CHINA |
| Brand Name: | WEIDE |
| Certification: | CE |
| Model Number: | 80ST-CJ102430L5-B |
| Document: | Weide Servo Catalogue-2504_...ed.pdf |
| Model Number | 80ST-CJ102430L5-B |
| Mathematical Model | Linear |
| Signal Type | Continuous |
| Certifications | CCC, ISO 9001, CE |
| Material | Aluminum Alloy |
| Input Power | Single/Three Phase AC220V |
| Temperature Range | Working: 0-40℃; Storage: -40-50℃ |
| Control Type | PWM Sine Wave Vector Control |
| Feedback Mode | 2500PPR Incremental Encoder |
| Control Mode | Position Control |
| Digital Inputs | Srv-on, Clear, CCW/CW Limits, etc. |
| Digital Outputs | Servo Ready, Alarm, Position Completed |
| Protection Functions | Overspeed, Overvoltage, Overcurrent |
| Package | Carton (355*305*310 mm) |
| Model No. | Output Power (KW) | Rated Torque (N.m) |
|---|---|---|
| 10B | 0.05-0.4 | 0.01-1.3 |
| 15B | 0.6-1.0 | 1.9-4 |
| 20B | 1.0-1.3 | 4-10 |
| 30B | 1.5-3.8 | 6-15 |
| Speed Frequency Response | >400Hz |
| Speed Fluctuation Ratio | <±0.03% (load 0-100%) |
| Speed Regulation Ratio | 1:5000 |
| IP Grade | IP20 |
| Humidity Range | Working: 40-80%; Storage: below 93% |
