Ld320 Reduces Startup Current Helping Motors Avoid Overcurrent Damage During Acceleration
Reduces startup current to help motors avoid overcurrent damage during acceleration
Product Overview
Model NumberLD320-800G-T4 Working PrincipleVector Control Transducer Switch ModePWM Control Main Circuit TypeCurrent Power Supply VoltageLow Voltage Variable-Frequency Drive Transformation LinkAC-DC-AC Variable-Frequency Drive DC Power NatureCurrent Variable-Frequency Drive FunctionSimple Type BrandLaeg Protection DegreeIP55/65 Voltage380V, or Customized Frequency50Hz, 60Hz Output Frequency0.01-400 Hz Transport PackageWooden Cases Specification12*9*9 cm TrademarkLAEG OriginAnhui, China HS Code8504400090 Production Capacity5000/Month
Company Profile
With over 55 years of construction and development, Lu'an Jianghuai Motor has become the largest industrialized enterprise in the small, medium and large motor industry, offering the most complete product series and comprehensive service network. ANHUI LAEG is the branch of Luan Jianghuai motor company, specializing in VFD production for over 20 years.
Inverter Advantages
- More compact size with advanced modular design, saving over 30% volume compared to same power inverters
- Better excitation performance with automatic motor excitation current adjustment
- Multiple display options including double selection or LCD operation panels
- All-drive capability for three-phase asynchronous motors, permanent magnet synchronous motors, and servo motors
- High reliability with long-life components and enhanced substrate coatings
Technical Specifications
ModelAD10-4R0G-T4-B Adapt Motor Power4kW / 5HP Rated Output Capacity5.9 KVA Rated Output Current9A Output Frequency0.01~400 Hz Carrier Frequency Range1~16 KHz Overload Capacity150% for 60s, 200% for 3s Input Current10.5A Input Voltage & Frequency3 phase 380V, 50~60Hz Voltage Range315V~450V Cooling SystemForced cold air Brake UnitIn-build
Input Voltage Specifications
Input Voltage Frequency Model Input Current (A) Motor Power (KW) Motor Horsepower (HP) Rated Output Capacity (KVA) Output Current (A) 1AC 220V 50/60HzAD10-0R7G-S2B8.20.7511.54 1AC 220V 50/60HzAD10-1R5G-S2B141.5237 1AC 220V 50/60HzAD10-2R2G-S2B232.2349.6 3AC 380V 50/60HzAD10-0R7G-T4B3.40.7511.52.1 3AC 380V 50/60HzAD10-1R5G-T4B51.5233.8 3AC 380V 50/60HzAD10-2R2G-T4B5.82.2345.1 3AC 380V 50/60HzAD10-4R0G-T4B10.53.755.99 3AC 380V 50/60HzAD10-5R5G-T4B14.65.57.58.913 3AC 380V 50/60HzAD10-7R5G-T4B20.57.5101117 3AC 380V 50/60HzAD10-011G-T4B2611151725
Inverter Applications
Factory Environment
Our motor factory scale and product line, products details
Certifications
We have CE, ISO9001, CCC and other certificates
Packaging
Frequently Asked Questions
Are you a factory or trading company?
LU'AN JIANGHUAI is a factory that has been focusing on motors and accessories for more than 50 years.
What about the warranty?
We offer 12 month warranty period as the quality guarantee.
Can you do OEM?
Yes, we offer OEM services.
How about your service?
We provide pre-sale service, in-sale service and after-sale service. Our principle is customer first for long-term cooperation.
What are your terms of delivery?
Generally we ship in FOB term, but we can offer solutions for CNF, CIF and DDP based on your requirements.
What's the delivery time?
15 to 35 days after receiving your payment in advance.
